LITE-IR4
INFRARED MULTIZONE CURING OVEN
Dimensions: 125 x 156 x 390 cm
Weight: 1200 kg
Delivery time: 150 days
LITE IR product line provides a lean and efficient process for curing various materials using a combination of IR and
convection heat sources. Lean design, maximum productivity and performance.

FEATURES
» Concept modular line.
» InLet/OutLet shutters standard.
» IR Radiation and combined convection
» Energy efficient.
» Patented digital radiation module with global close looped thermal imaging of the product.
» Patented selective heat.
» VOC filtering management.
» Auto adjust extraction Air Flow based on VOC density.
Component clearence
150 mm top and bottom
Volumen
7.61 m³
Largo
3.9 m
Ancho
1.25 m
Alto
1.56 m
Peso
1200 kg
